Brompton G Line - 20 inch wheel size folding bike
The G Line - Gravel? Line range was introduced by Brompton with the 2024 lineup of bikes
It's now a very popular option
It has larger wheels than the traditional 16 inch Brompton size at 20 inches
Brompton G Line specification:
1/ Frame |
The G Line - Gravel? Line range was introduced by Brompton with the 2024 lineup of bikes
Main Frame: | Steel |
Rear frame / triangle: | Steel |
Handlebar stem: | Alloy with water bottle mounting bosses |
Front forks: | Alloy with mounting bosses |
Folded size: 71cm wide x 68cm tall by 38cm deep (approx)
2/ Colour |
At the time of launch in autumn 2024 the G Line was available in 3 colours:
- Adventure Orange
- Space Grey
- Traildust White
For the 2026 model year a new colour was added in autumn 2025:
- Forest Green
Main frame: Colour choice of Orange, Dark Grey, Off White or Dark Green - all the paintwork has a textured finish
Rear frame / triangle: Colour matches the main frame
Handlebar stem: Black
Front forks: Colour matches the main frame
Decal: Depending upon frame colour
3/ Size |
Available in three sizes:
- Small
- Medium
- Large
The G Line only has one handlebar type - ride position is dictated entirely by the stem length and seat post length
Handlebar width - 65cm
4/ Gears / drivechain |
8 speed Shimano Alfine hub gear system with single 20T rear sprocket
54T front chainring - black (also available as 50T or 44T - we can change at no extra cost)
Brompton advance chain with connecting link - 114 links
Brompton flat platform pedals (the right one is removable)
5/ Front luggage system |
The G line comes with a front carrier block fitted
6/ Mudguards / Rack |
This bike comes with black mudguards and rack as standard to help keep you protected to some degree from the elements
7/ Roller Wheels |
New larger roller wheels help keep the bike stable when folded
8/ Wheels / Tyres |
20 inch wheel size
TRP / Tektro hydraulic disc brakes
The wheels have black hubs, black spokes and black rims
Presta / racing type valve
Schwalbe G One with tan wall (ETRTO size 54-406) - tubeless ready
Low rolling resistance and good puncture protection
If you would like to change to Continental Contact Urban tyres for lower rolling resistance and designed primarily for on-road use - we can make this change at no additional cost (note that the Contact Urban tyres can not be made tubeless)
9/ Saddle |
Standard Brompton saddle 143mm wide
With lighting mount point underneath the saddle
10/ Seat height |
The seat height is dictated by the bike size
Small size G Line bikes come with a Brompton standard length seatpost
Medium size G Line bikes come with a Brompton extended length seatpost (6cm longer than the standard length which means that the fully folded position is slightly higher)
Large size G Line bikes come with a telescopic seatpost
11/ Suspension |
Along with the new G Line comes a new advance suspension block
12/ Lighting / Reflectors |
Front and rear reflectors are included
It's easy to retrofit battery lighting such as:
- Brompton Cateye VIZ150 rear light - mounts on the Brompton saddle
- Brompton Lezyne G Line front light with bracket
- Brompton G Line Be Seen light set
| Colour | Space Black, Forest Green, Adventure Orange, Traildust White |
| Size | small, medium, large |
